产品特点 | Feature
n Three dimensional force sensor
n Senior alloy steel
n Easy to install
n Height of low rogidity
n Suitable for industrial weighing systems, overload protection on robot heads, testing machine. etc
l 三维力传感器
l 优质合金钢材质
l 安装简便
l 高度低 刚性好
l 适用于工业称重系统，机器人手过载保护测式设备等
l 量程 | Capacities
l X:25/50N,Y：25/50N,Z:50/100N
l 客户可以根据自己需求定制量程。
技术参数 | Specification
|
Rated Output |
额定输出 |
1.0mv/v±1% |
|
Zero Balance |
零点平衡 |
±1% of rated output |
|
Creep After 30 Minutes |
蠕变 |
±0.2% of rated output |
|
Nonlinearity |
非线性 |
±0.5% of rated output |
|
Hysteresis |
滞后 |
±0.5% of rated output |
|
Repeatability |
重复性 |
±0.2% of rated output |
|
Temp. effect on output |
灵敏度温漂 |
≤0.05% of applied output/℃ |
|
Temp. Effect on zero |
零点温漂 |
≤0.05% of rated output/℃ |
|
Safe temp. Range |
可用温度范围 |
-10℃ to+70℃ |
|
Temp.Compensated |
温度补偿范围 |
-10℃ to+40℃ |
|
Safe Overload |
安全载荷 |
150% |
|
Input Impedance |
输入阻抗 |
700 Ω±10Ω |
|
Output Impedance |
输出阻抗 |
700 Ω±10Ω |
|
Insulation Resistance |
绝缘阻抗 |
≥5000MΩ(50V DC) |
|
Rated Excitation |
推荐激励电压 |
10V DC/AC |
|
Protection Class |
防护等级 |
IP67 |
|
Construction |
电线 |
0-15t(3m)35-100t(12m) |
|
type |
型号说明 |
型号+‚量程+ƒ非标功能F(无非标则不需填写) 如：CL-TR4/35X50Y100Z |
|
Cable Color Code |
导线颜色 |
EXC:Blue(+E) Black(+E) XSIG:Gray(+S) YSIG:Brown(+S) Yellow(-S) ZSIG:White(+S) Red(-S) |
注：资料仅供参考，具体以实际订货为准。
